Water Fire Extinguisher
WP-61-2For commercial and industrial Class A fires.
Heavy-duty chrome plated brass valves
Comfortable stainless steel handles and operating levers
Large loop stainless steel pull pins with retention tether
Hex valve collar tightening ring for easy recharge
Images are representative only.
Actual product may vary slightly.
Specifications
| Agent charge | Water |
| Brackets included | UB-20 Optional |
| Cylinder | Steel |
| Diameter x height | 8.75 inches 24.75 inches |
| Discharge range | 30.0 to 45.0 |
| Discharge time | 55 sec |
| Govt agency approved | DOT |
| Model | WP-61-2 |
| Operating pressure | 100 |
| Single use or rechargeable | Rechargable |
| U l rating | 2-A |
| Unit weight average | 2.5 lb |
| Valve handle lever | Stainless Steel |
| Warranty | 6 year limited |
Badger’s water extinguisher is ideal for Class A fires involving common combustibles such as trash, fabrics, wood and paper. Water is economical and easy to clean up. The Badger model WP-61 water fire extinguisher has additionally been UL tested and listed as a “Loaded Stream” fire extinguisher. When properly charged using the Badger AC-40 potassium acetate loaded stream charge (P/N 00792) this extinguisher is approved for low temperature applications down to -40°F (-40° C). For specific recharge instructions, refer to the nameplate and service manual (P/N 24642). The time proven design of the Badger WP-61 Water fire extinguisher makes it extremely effective, simple to use, inexpensive and easy to recharge.
- Heavy-duty chrome plated brass valves
- Comfortable stainless steel handles and operating levers
- Large loop stainless steel pull pins with retention tether
- Hex valve collar tightening ring for easy recharge
- UL listed—Meets D.O.T. requirements
- Six year warranty
- Full stainless steel cylinder and base
- Easy-to-read two-piece nameplates
Product Documentation
Specifications
| Agent charge | Water |
| Brackets included | UB-20 Optional |
| Cylinder | Steel |
| Diameter x height | 8.75 inches 24.75 inches |
| Discharge range | 30.0 to 45.0 |
| Discharge time | 55 sec |
| Govt agency approved | DOT |
| Model | WP-61-2 |
| Operating pressure | 100 |
| Single use or rechargeable | Rechargable |
| U l rating | 2-A |
| Unit weight average | 2.5 lb |
| Valve handle lever | Stainless Steel |
| Warranty | 6 year limited |
Product Documentation
Badger’s water extinguisher is ideal for Class A fires involving common combustibles such as trash, fabrics, wood and paper. Water is economical and easy to clean up. The Badger model WP-61 water fire extinguisher has additionally been UL tested and listed as a “Loaded Stream” fire extinguisher. When properly charged using the Badger AC-40 potassium acetate loaded stream charge (P/N 00792) this extinguisher is approved for low temperature applications down to -40°F (-40° C). For specific recharge instructions, refer to the nameplate and service manual (P/N 24642). The time proven design of the Badger WP-61 Water fire extinguisher makes it extremely effective, simple to use, inexpensive and easy to recharge.
- Heavy-duty chrome plated brass valves
- Comfortable stainless steel handles and operating levers
- Large loop stainless steel pull pins with retention tether
- Hex valve collar tightening ring for easy recharge
- UL listed—Meets D.O.T. requirements
- Six year warranty
- Full stainless steel cylinder and base
- Easy-to-read two-piece nameplates
